ASUS GX601 ROG STRIX HELIOS WHITE

Product Type: Full Tower PC CaseSeries: ROG StrixModel: ASUS ROG Strix Helios GX601Color: Black
General
Motherboard Support:

E-ATX (Up to 12″ × 10.9″)

ATX

Micro-ATX

Mini-ITX

Storage Support
Drive Bays:

2 × 2.5″ Dedicated Bays

2 × 2.5″/3.5″ Combo Bays

Expansion
Expansion Slots: 8 + 2 Vertical Expansion Slots
Front I/O
USB Ports:

4 × USB 3.2 Gen 1 Type-A

1 × USB 3.2 Gen 2 Type-C

Audio:

1 × Headphone / Microphone Combo Jack

Controls:

Power Button

Reset Button

LED Control Button

Fan Control Button

Radiator Support
Front:

Up to 420mm

360mm

280mm

240mm

140mm

120mm

Top:

Up to 360mm

280mm

240mm

140mm

120mm

Rear:

140mm

120mm

Cooling Support
Front:

3 × 140mm

3 × 120mm

Top:

3 × 140mm

3 × 120mm

Rear:

1 × 140mm

1 × 120mm

Pre-Installed Fans
Front:

3 × 140mm PWM Fans

Rear:

1 × 140mm PWM Fan

Clearance
Maximum CPU Cooler Height: 190mmMaximum Graphics Card Length: 450mm (Without Front Radiator)Maximum PSU Length: 220mm
Dust Protection
Removable Dust Filters:

Front

Top

Bottom

Cable Management
Cable Management Space: 34mm Wide Cable Routing Channel with Velcro Straps and Multi-Function Cover
Dimensions & Weight
Dimensions (L × W × H): 565 × 250 × 591mmWeight: 18kg
